Η σειρά μητρικών Workstation της ASUS είναι η ιδανική βάση για έναν ισχυρό υπολογιστή. Παρέχει ανεπανάληπτες δυνατότητες, υψηλές επιδόσεις και ασύγκριτη συνδεσιμότητα για όλες τις λειτουργίες και οποιαδήποτε μελλοντική αναβάθμιση.
- Τοποθέτηση: CEB Form Factor
- Υποστήριξη CPU: Intel Socket 2011 Core i7 Processors, Intel Socket 2011 for Xeon E5-1600/E5-1600 v2 processors, Intel Socket 2011 for Xeon E5-2600/E5-2600 v2 processors
- Chipset: Intel X79
- Μνήμες: 8 x DIMM, Max. 64GB, DDR3 2400(O.C.)/2133(O.C.)/1866(O.C.)/1866/1600/1333/1066 MHz ECC, Non-ECC, Un-buffered Memory *1, Quad Channel Memory Architecture
- Multi-GPU Υποστήριξη: Supports NVIDIA 4-Way SLI Technology, Supports AMD 4-Way CrossFireX Technology
- Θέσεις Επέκτασης: 7 x PCIe 3.0/2.0 x16 (single x16 or dual x16/x16 or triple x16/x16/x16 or quad x16/x16/x16/x16 or seven x16/x8/x8/x8/x16/x8/x8, black+blue) *2
- Δίσκοι: Intel X79 chipset : 2 x SATA 6Gb/s port(s), 4 x SATA 3Gb/s port(s), Support Raid 0, 1, 5, 10 Marvell PCIe 9230 controller : 4 x SATA 6Gb/s port(s), Support Raid 0, 1, 10, ASMedia PCIe SATA controller : 2 x eSATA 6Gb/s port(s)
- LAN: Intel I210, 2 x Gigabit LAN Controller(s)
- Ήχος: Realtek ALC1150 8-Channel High Definition Audio CODEC
- IEEE 1394: VIA 6315N controller 1 x IEEE 1394a port(s)
- USB Ports: ASMedia USB 3.0 controller : 4 x USB 3.0/2.0 port(s) (2 at back panel, blue, 2 at mid-board), Intel X79 chipset : 13 x USB 2.0 port(s) (10 at back panel, black, 3 at mid-board)
- Πίσω I/O Θύρες: 1 x PS/2 keyboard/mouse combo port(s), 2 x eSATA 6Gb/s, 2 x LAN (RJ45) port(s), 2 x USB 3.0 (blue), 10 x USB 2.0 (one port can be switched to USB BIOS Flashback), 1 x Optical S/PDIF out, 8 x Audio jack(s), 1 x USB BIOS Flashback Button(s)
- Εσωτερικές I/O Θύρες: 1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s) (19-pin), 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s), 1 x Vertical USB 2.0 port(s), 1 x TPM connector(s), 1 x COM port(s) connector(s), 6 x SATA 6Gb/s connector(s), 4 x SATA 3Gb/s connector(s), 1 x CPU Fan connector(s) (4 -pin), 1 x CPU OPT Fan connector(s) (4 -pin), 4 x Chassis Fan connector(s) (4 -pin), 1 x S/PDIF out header(s), 1 x 8-pin EATX 12 V Power connector, 1 x 6-pin EATX 12 V_1 Power connector(s), 1 x 24-pin EATX Power connector(s), 1 x Front panel audio connector(s) (AAFP), 1 x System panel(s) (Q-Connector), 1 x Chassis Intrusion connector(s)*3, 1 x MemOK! button(s), 1 x TPU switch(es), 1 x EPU switch(es), 1 x Power-on button(s), 1 x Reset button(s), 1 x Clear CMOS jumper(s), 1 x Dr.Power switch(es)
